Tapered Sleeve 3/8″ port

58130_v0

$123.70 Suggested Retail

Part #: 58130

Product Description

  • Maximum Extended Height: 9.5″
  • Compressed Height: 4.25″
  • Maximum Diameter: 5.4″
  • Maximum Load at 100 PSI: 1,216 lbs.
  • Design Height: 6.5-8.5″
  • Air Fitting Size: 3/8″
  • Top Fastener: 3/8″ – 24
  • Bottom Fastener: 3/8″ – 16
  • Mounting Hole Center: 2.75″ – Top/Center/Bottom
